Connecting Cables and Setting Switches
This section takes you through all the connections and switch settings necessary on the mother-
board. This will include:
Power Connections
24-pin ATX power
8-pin ATX 12V power
Internal Headers
Front panel
IEEE 1394a
USB headers
Audio
Speaker
COM
FDD
IDE
Serial ATA II
Chassis Fans
Rear panel USB 2.0 Adapter
Expansion slots
See Figure 1 on page 4 to locate the connectors referenced in the following procedure.
