Channel 1, 2, and 3 will not work, when Channel 4 is being
used.
When using Channel 4, Channel 5 will control the speed of the
macro.
Channel Value Function
1 0 - 255 RED
0% 100%
2 0 - 255 GREEN
0% 100%
3 0 - 255 BLUE
0% 100%
4 16 - 255 COLOR MACRO
5 0 - 15 NOTHING
16 - 255 STROBING
6 0 - 255 DIMMING
0% 100%
ELED TRI PAR56 6 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 RED
0% 100%
2 0 - 255 GREEN
0% 100%
3 0 - 255 BLUE
0% 100%
4 16 - 255 COLOR MACRO
5 0 - 15 NOTHING
16 - 255 STROBING/SPEED CONTROL
6 MODE
0 - 127 NOTHING
128 - 159 AUTO MIX COLOR
160 - 191 3 COLOR CHANGE
192 - 223 7 COLOR CHANGE
224 - 255 SOUND ACTIVE
7 0 - 255 DIMMING
0% 100%
ELED TRI PAR56 7 Channel - DMX Values & Functions
Channel 1, 2, and 3 will not work, when Channel 4 is being
used.
When using Channel 6, Channel 5 will control the speed of the
color changing.
