ELED TRI PAR56 Operating Instructions
DMX Mode:
Operating through a DMX controller gives the user the freedom to create
their own programs tailored to their own individual needs. This function
also allows you to use your fixtures as spot lights. The ELED TRI PAR56
has 6 DMX modes: 1 Channel mode, 2 Channel mode, 3 Channel mode,
4 Channel mode, 6 Channel mode, and a 7 Channel mode. See pages
10-12 for each modes’ DMX traits.
1. This function will allow you to control each individual fixture’s traits
with a standard DMX 512 controller such as the Elation® Show
Designer™ or the Elation® DMX Operator™.
2. To run your fixture in DMX mode, plug in the fixture via the XLR con-
nections to any standard DMX controller. Select your desired DMX
mode, and then press the UP or DOWN buttons to adjust the DMX
address.
3. To run the 1 Channel Mode, press the MODE button until “1000”
is displayed. This is the DMX addressing for the 1 Channel Mode.
4. To run the 2 Channel Mode, press the MODE button until “2000”
is displayed. This is the DMX addressing for the 2 Channel Mode.
5. To run the 3 Channel Mode, press the MODE button until “3000”
is displayed. This is the DMX addressing for the 3 Channel Mode.
6. To run the 4 Channel Mode, press the MODE button until “4000”
is displayed. This is the DMX addressing for the 4 Channel Mode.
7. To run the 6 Channel Mode, press the MODE button until “5000”
is displayed. This is the DMX addressing for the 6 Channel Mode.
8. To run the 7 Channel Mode, press the MODE button until “6000”
is displayed. This is the DMX addressing for the 7 Channel Mode.
9. Please see pages 10-12 for DMX values and traits.
ELED TRI PAR56 1 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 MACROS
ELED TRI PAR56 2 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 MACROS
2 0 - 255 DIMMER 0% - 100%
ELED TRI PAR56 3 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 RED
0% 100%
2 0 - 255 GREEN
0% 100%
3 0 - 255 BLUE
0% 100%
ELED TRI PAR56 4 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 RED
0% 100%
2 0 - 255 GREEN
0% 100%
3 0 - 255 BLUE
0% 100%
4 0 - 255 DIMMING
0% 100%
