3.31 If locating the CO alarm in a bedroom or in rooms remote from a fuel
burning appliance (see figure 4)
• Mount the CO alarm relatively close to the breathing zone of the occupants.
Whatever position is chosen make sure it is possible to view the three light indicators,
when in the vicinity of the alarm.
14
CO Alarm
about
1 to 2m
Figure 4. Location in bedroom &
rooms remote
from the appliance
(i.e. at breathing level)
300mm
CO Alarm
Figure 3. Location in rooms with
sloped ceilings, the CO alarm should
be located at the high side of the room
