Edirol MA-1EX - Manual (Page 8)

8
Getting Connected and Installing Drivers English
Windows 98 users
* The driver necessary for using the MA-1EX
with Windows 98 is provided on the Windows
CD-ROM. Make sure that you have the
Windows CD-ROM available.
* Some computers are sold with the contents of
the Windows CD-ROM stored on the hard
disk, and therefore will not come with a
Windows CD-ROM. If this is the case for your
computer, you’ll be able to install the driver
even without the Windows CD-ROM.
* The USB composite device driver is
installed first, then the USB audio device
driver is installed. Use the following
procedure to install the drivers.
1. With the MA-1EX disconnected, start up
Windows.
* Disconnect all USB cables except for a USB
keyboard and USB mouse (if used).
* Exit all currently running software
(applications).
If you are using a virus checker or similar
software, be sure to exit it as well.
2. Use the USB cable to
connect the MA-1EX to
your computer, and
turn on the MA-1EX’s
power (turn the
VOLUME knob toward the right).
* This unit is equipped with a protection circuit.
A brief interval (a few seconds) after
connecting a USB connector is required before
the unit will operate normally.
3. USB composite device will be detected
automatically, and the “Add New
Hardware Wizard” dialog box will
appear. Click [Next] .
4. When “What do you want Windows to
do?” appears, select “Search for the
best driver for your device
(Recommended)
, ” and click [Next] .
fig.05-27e_30
5. A dialog box like the one shown will
appear.
Check
CD-ROM drive , and click [Next] .
* If the display indicates “Can’t find an updated
driver for this device , ” check “Updated
driver , ” and click [Next] .
6. A dialog box like the one shown will
appear.
Click
[Next] .
* Depending on your system, the Driver
location may differ from the illustration, but
this is not a problem.
7. File (driver) copying will begin.
If the Windows CD-ROM is not inserted
in the CD-ROM drive, a “Insert Disk”
dialog box may appear. In this case, insert
the Windows CD-ROM into the CD-ROM
drive and click [OK].
MA-1EX_efgis.book 8 ページ ２００５年１０月３１日 月曜日 午後２時３０分
