RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES)
Cross section
through cabinet
showing oven
positioned
Fig.3 Built Under Installation
Fig.4 Built In Installation
570
600
560 min
570 max
550 min
600
595
540
5
595
5
5
5
5
570
585
540
600 min
560 min
570 max
550 min
2000 Rec
om
m
ended
Cross section
through cabinet
showing oven
positioned
