603691 High speed sandwich grill 208V/1ph/60Hz
Item No. ___________________________________
The Electrolux High Speed Grill is the fastest sandwich grill in
the world. Using breakthrough Microwaves in combination
with Infrared technology, cooking times can be reduced up to
75% while delivering superior sandwich quality by combining
simultaneously infrared radiation, contact plates and
microwaves you can perfectly toast and warm up the core of
your favourite panini for a Great Tasting, Hot and Crispy
Sandwich in less than 60 seconds.* Just place your sandwich
on the cooking surface and close the lid. The HSG will self
adapt the upper grilling plate and automatically open the lid for
you when the sandwich is ready. When not in operation, the
HSG will automatically enter in stand by mode reducing the
energy consumption.
*Depending on the cooking mass.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
High Speed Grill
Technical Specs
• AISI 304 S/S lid and top plate.
• AISI 430 S/S back cover and galvanized steel bottom cover.
• Painted steel side panels.
• Aluminium ribbed top contact plate (8 7/16 ″ × 8 7/16″) treated with
a special non-stick coating.
• The self adjusting top plate makes it possible to grill sandwiches
from 3/8 ″ up to 3″ thick.
• Smooth 4 mm thick quartz glass bottom cooking surface
(9 13/16 ″ × 9 13/16″).
• Independent temperature setting of the top and bottom plates from
320 to 536°F.
• Automatic holding and opening system controlled by an
electromagnet.
• Automatic lifting of the lid at the end of the cooking cycle via gas
spring.
• Electronic control with digital LED display.
• Countdown display and buzzer at the end of the cycle.
• 2 temperature probes for an independent control of the top and
bottom plate temperature.
• 900W MICA heating element on the top plate.
• 900W electrical armored heating elements on the bottom plate.
• 2 × 1000W magnetrons for microwave.
• Side louvres for efficient cooling ventilation.
• Ergonomic aluminium handle with plastic grip.
• Removable front panel and dismountable upper plate for better
cleanability.
• Supervisor mode to program up to 4 cooking cycle.
• Programmable parameters:
- top plate temperature¹
- bottom plate temperature¹
- duration of cycle
- duration of microwave within each cycle
- Stand-by delay
- Stand-by temperature
• IP24 protection index.
• 78 3/4 ″ cable included.
¹ the temperature remains fixed for all cooking cycles
