6. Turn off the control and check that the
oven flames go out.
To set the time of day
Please refer to the Timer section.
General information
Instruct the user on how to use the appliance
and its ignition system.
Refer the user to the wording on the inside
cover which gives advice on the safe opera-
tion of the appliance.
Technical data
Dimensions
Height 900 mm (nominal)
Width 600 mm (nominal)
Depth 600 mm (to front of door panel)
Weight 66 Kg Net
Space for fixing at hotplate level 2mm mini-
mum clearance.
Space for fixing above hotplate level See im-
portant note 'Location of Appliance'.
Minimum space above hoptplate 750mm (If
cooker hood is fitted refer to the cooker hood
installations.
Minimum distance from rear wall 5mm
(spacer given by pressed spacer on vent
panel). Connections
Gas connection:- Rear left hand side of ap-
pliance at hotplate level Rc ½ (½" B.S.P. fe-
male)
Electrical connection:- 230 - 240 V 50 Hz
Mains connected at rear centre of appliance
using at least 6mm2 multi core PVC insulated
cable.
Loading info : Gas hob
Natural Gas R.H.F R.H.R L.H.R L.H.F
Heat input 1.0kW (3412 Btu/
h) 1.9kW (6483 Btu/
h) 1.9kW (6483 Btu/
h) 3.4kW (11600
Btu/h)
Injector Marking 070 096 096 136
L.P. Gas R.H.F R.H.R L.H.R L.H.F
Heat input 1.0kW 2.0kW 2.0kW 3.4kW
Injector Marking 050 (71.8g/h) 071 (136.5g/h) 071 (136.5g/h) 093 (244.12g/h)
Loading info : Grill
Natural Gas L.P. Gas
Heat input 2.7kW (9212Btu/h) 2.7kW (194g/h)
Injector Marking 120 95
Loading info : Top oven
Natural Gas L.P. Gas
Heat input 1.9kW (6483 Btu/h) 1.9kW (136.5g/h)
Injector Marking 099 070
Dual control by-pass marking 50 38
electrolux 25
4. After 1 minute check that the flame cov-
ers the full width of the burner and is sta-
ble.
5. Set the oven control to Mk 2, close the
oven door and check that after about 10
minutes the flame size has reduced.
