2
Camera Unit x 1
Mounting kit includes:
-Screws x 4
-Security wrench for housing screws x 1
-Expanding Screws x 4
-Washers x 4
Operation Instructions (this document) x 1
Weatherproof bushing x 1
Power cable x 1
Video cable x 1
Power adapter pigtail (for NTSC model only) x 1
Mounting template x 1
SPECIFICATIONS
Pickup Device 1/3" SONY Super HAD CCD Sensor
Video Format NTSC or PAL (depends on model selected)
Picture Elements 768 x 494 (NTSC), 752 x 582 (PAL)
Horizontal Resolution 540 TVL
Sensitivity 0.12 LUX / F1.6 ; 0 LUX (IR LED ON)
S/N Ratio Over 48dB (AGC off)
Electronic Shutter 1/60(1/50)s~1/100,000s
Video Output BNC 1.0Vp-p 75Ω
Gamma Correction 0.45
Lens Type Vari-Focal 3.7~12mm / F1.4 DC Drive Auto Iris Lens
Day/Night True day/night with motorized IR cut filter
Gain Control Automatic
White Balance ATW (2500°K~9500°K)
Sync. Mode Internal Sync.
IR LED 11 Units High Efficiency IR LED
IR Wavelength 850nm
IR Distance 25m (~80ft.) nominal; depends on environment
Weather Resistant IP 66
Vandal Proof Yes
Power Source 12VDC
Power Consumption 283mA @12VDC
Operating Temperature -10°C~50°C / 14°F~122°F
Dimensions (O.D. x H) 142mm x 115.5mm / 5.6” x 4.55”
Weight 979 g / 2.16 lbs
Certifications CE / FCC
