VIVOTEK
User's Manual - 43
Video Stream: This Network Camera supports multiple streams (stream #1 ~ #4) simultaneously. You
can select any one of them for live viewing. For more information about multiple streams, please refer to
page 79 for detailed information.
Manual Trigger : Click to manually enable or disable an event trigger. Please configure an event setting
before enabling this function. A total of 3 or 4 event settings can be configured. For more information
about event setting, please refer to page 127. If you want to hide this item on the homepage, please go
to the System > Homepage Layout > General settings > Customized button to deselect the “show
manual trigger button” checkbox.
Digital Output : Click to turn the digital output device on or off.
PTZ Control Panel:
Pano.: Click this button to start the automatic horizontal pan (360° continuous rotation).
Stop: Click this button to stop the Auto Pano and Auto Rotate functions.
Rotate : Once the Administrator has configured the list of preset positions (including the zoom-in action
on a particular position), click this button to command the camera to display the preset positions in a
consecutive order. The Network Camera will display those positions continuously. For more information,
please refer to PTZ control on page 124.
Left
Down
Zoom Out
Start the Panoramic
rotation
Stop Auto Pano or Rotate
Return to Home Position
Right
Up
Zoom In
Rotate
