VIVOTEK
174 - User's Manual
xcount-1)>
7.2status
Group: status
NAME VALUE SECURITY
(get/set) DESCRIPTION
di_i<0~(capability_ndi-1)>
1/7 0 => Inactive, normal
1 => Active, triggered
(capability.ndi > 0)
do_i<0~(capability_ndo-1)>
1/7 0 => Inactive, normal
1 => Active, triggered
(capability.ndo > 0)
onlinenum_rtsp 0,
integer>
6/7 Current number of RTSP connections.
onlinenum_httppush 0,
integer>
6/7 Current number of HTTP push server
connections.
onlinenum_sip 0,
integer>
6/7 Current number of SIP connections.
eth_i0 1/7 Get network information from mii-tool.
vi_i<0~(capability_nvi-1)>
1/7 Virtual input
0 => Inactive
1 => Active
(capability.nvi > 0)
7.3digital input behavior define
Group: di_i<0~(n-1)> for n is the value of "capability_ndi" (capability.ndi > 0)
NAME VALUE SECURITY
(get/set) DESCRIPTION
normalstate high,
low
1/1 Indicates open circuit or closed circuit
(inactive status)
7.4digital output behavior define
Group: do_i<0~(n-1)> for n is the value of "capability_ndo" (capability.ndo > 0)
NAME VALUE SECURITY
(get/set) DESCRIPTION
normalstate open,
grounded
1/1 Indicate open circuit or closed circuit (inactive
status)
