26
● : Solid ON
★ : Flash
↑ : LED display and alarm warning are dependent on other conditions.
14 Utility power abnormal ↑ ↑ ↑ ↑ ● ★ ↑ ↑ ↑ ↑
15
Overloaded in battery
mode,
Early-warning ● ● ↑ ↑ ↑ ↑ ● ●
Beep twice
every sec.
16
Overloaded in battery
mode,
Cut off the output
● ●
Continuously
beep
17 Over temperature ● ● ↑ ↑ Continuously
beep
18 Inv abnormal ● ● ↑ ↑ Continuously
beep
19 Output short circuited ● ● ● ↑ ↑ Continuously
beep
20 BUS voltage abnormal ● ● ↑ ↑ Continuously
beep
21 Charger or battery failed ● ● ● ↑ ↑ ★ Continuously
beep
22 Battery voltage
abnormal
↑ ↑ ↑ ↑ ↑ ● ● ★ ↑
23 BAT SCR failed ● ● ● Continuously
beep
24 Fan abnormal ● ● ● ● ● Continuously
beep
25 Bypass STS failed ● ● ● ● ● Continuously
beep
26 INV RLY failed ● ● ● ● ● Continuously
beep
27 Communication
abnormal
● ● ● ↑ ↑ Continuously
beep
