Dimension Drawings:

Top View

Front View

Bottom View

WARNING

The SB2A is very lightweight and has a small footprint. Do not

attempt to pole-mount a speaker system larger than a Zx1 or

Sx80 on the SB2A.

SB2A Part Numbers

PRD000110-001 SB2A, Black Finish

PRD000110-002 SB2A, White Finish

Performance Match

Zx1, 8-inch Two-Way Portable Loudspeaker

Sx300, 12-inch Two-Way Portable Loudspeaker

SB122, 12-inch Portable Bass Module

Accessories

302055-000

ASP-1, Adjustable Sub Pole

5912525

PDSx, Carrying Bag

302053-001

TSS-1, Tripod Stand

Frequency Response & Impedance:

Block Diagram:
