8

1.

POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter.

2.

THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle trigger is

prevented unless throttle trigger lockout lever is engaged.

3.

STOP SWITCH - "SLIDE SWITCH" mounted on top of the Throttle Trigger Housing. Move switch FORWARD to

RUN, BACK to STOP.

4.

THROTTLE TRIGGER - Controls engine speed. Spring loaded to return to idle when released. During acceleration,

press trigger gradually for best operating technique.

5.

DRIVE SHAFT ASSEMBLY - Includes the Rear (right hand) Handle assembly, Gear Housing assembly, Front (loop,

left hand) Handle assembly, steel drive shaft and Safety Decal.

6.

BLADE - Circular blade for grass, weed or brush cutting applications. Harness, metal shield & U-handles required for

blade operation.

7.

METAL BLADE SHIELD - Required when unit is equipped with blades. Do not operate unit without shield.

8.

U-HANDLE - Required for metal blade operation.

9.

HIP PAD - Used to protect hip/leg and clothing when using U-handle equipped unit.

10. SHOULDER HARNESS- An adjustable strap that suspends the unit from the operator. Using the strap reduces

operator fatigue and restricts rearward movement of unit.

11. PLASTIC DEBRIS SHIELD ASSEMBLY - Included in plastic bag (co-pack). MUST be installed on unit before use,

see Assembly Instructions. Shield assembly includes the Cut-Off Knife. Mounts on the Gear Housing Assembly just

above the cutting attachment. Helps protect the operator by deflecting debris produced during the trimming opera-

tion. This shield must be replaced with the steel shield for blade use.

12. CUT-OFF KNIFE - Automatically trims line to the correct length: 5" after head is tapped on the ground. If trimmer is

operated without a cut-off knife, the line will become too long, the engine will overheat, and engine damage may

occur.

13. NYLON CUTTER HEAD - Contains replaceable nylon trimming line that advances when the trimmer head is tapped

against the ground while the head is turning at normal operating speed.

14. SPARK PLUG - Provides spark to ignite fuel mixture.

15. ARM REST - Provides arm rest during operation and protects arm from the hot engine.

16. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER -The muffler or catalytic muffler controls exhaust noise

and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep

exhaust area clear of flammable debris.

17. FUEL TANK - Contains fuel and fuel filter.

18. RECOIL STARTER HANDLE - Pull handle slowly until starter engages, then quickly and firmly. When engine

starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.

19. FUEL TANK CAP - Covers and seals fuel tank opening.

20. PURGE BULB - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging air from the

carburetor. Pump purge bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump purge bulb

an additional 4 or 5 times.

21. AIR CLEANER - Contains replaceable filter element.

22. CHOKE - The choke control is located at the rear of the air cleaner housing. Move choke lever to Cold Start (

) to

close choke for cold start. Move choke lever to "Run" (

) position to open choke.
