Tools Needed for Assembly
One Phillips head screwdriver
One wire stripper
Six wire connectors (supplied)
Three 60-watt (max.) candelabra base bulbs
Materials
Wiring, outlet box and box connectors
must be of type required by the local code.
The minimum wire would be a 3-conductor
(2-wire with ground) of the following sizes:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
This Manual Is Designed to Make it as Easy as Possible for You to
Assemble, Install, Operate and Maintain Your Ceiling Fan
Unpacking Instructions
For your convenience, check-off boxes
are provided next to each step. As each
step is completed, place a check mark
in the box. This will insure that all steps
have been completed and will be help-
ful in finding your place should you be
interrupted.
Do not install or use fan if any part is
damaged or missing. Call Toll-Free:
1-800-654-3545
! WARNING
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson Electric
Co. could result in personal injury or
property damage.
! WARNING
a. Fan motor and housing assembly
b. One ceiling cover
c. One adapter/light fitter assembly
d. Five fan blades
e. Five blade flanges
f.
One hanger bracket
g. One hanger ball/downrod assembly
h. One lower ring assembly (with six ring
screws attached)
i. One lower glass
j. One remote control transmitter
k. One remote control receiver
l.
One loose parts bag, containing:
1. Two 1-1/4” threaded studs
2. Two knurled knobs
3. Two lockwashers
4. Seven wire connectors
5. One hairpin clip
6. One clevis pin
7. Eleven 1/4-20 x 11mm pan head
screws with lockwashers
8. Sixteen 10-24 x 9mm truss
head screws
9. Sixteen fiber washers
10. Four 8-32 x 12mm pan head screws
NOTE: Place the parts from the loose parts
bags in a small container to keep them from
being lost. If any parts are missing, contact
your local retailer or catalog outlet for
replacement before proceeding.
B
C
E
K
A
F
L I
H
H I OFF
LOW MED
J
D
G
1. Open styrofoam unit containing fan.
Remove top half of styrofoam unit.
Remove parts and check to see that
you have received the following parts:
NOTE: If you are uncertain of part
description, refer to exploded view
illustration.
