Rx − 8801 sa / je – Epson RX-8801SA/JE User Manual
Page 32
RX
− 8801 SA / JE
Page - 29
ETM26E-03
9.2. RX
− 8801 JE
( VSOJ − 20pin )
9.2.1. External dimensions
RX
− 8801 JE
( VSOJ − 20pin )
• External dimensions • Recommended soldering pattern
0.65
0.22
1.3 1.5 Max.
0.12
0.1
0 Min.
6.0
± 0.2
(0.75)
(0.75)
Unit : mm
1.5
3.8
1.5
0.65
× 9 = 5.85
0.3
0.35
0.65
5.4
7.0
± 0.3
#1
#20 #11
#10
∗
The cylinder of the liquid crystal oscillator can be seen in this area ( back and front ),
but it has no affect on the performance of the device.
9.2.2. Marking layout
RX
− 8801 JE
( VSOJ − 20pin )
Logo
Type
Production lot
R
8801
E
A123B
∗ Contents displayed indicate the general markings and display, but are not the standards for the fonts, sizes and positioning.
