Specifications
Tread Width: (Center to Center of
Tires, Widthwise)
60 inch Deck 72 inch Deck
Drive Wheels 41.6 inches
(105.7 cm) 43.6 inches
(110.7 cm)
Caster Wheels 39.5 inches
(100.3 cm) 47.1 inches
(119.6 cm)
Wheel Base: (Center of Caster Tire to
Center of Drive Tire)
LZZ-LP Units:
60 inch Deck
50.6 inches (128.5 cm)
LZAS-LP Units:
60 inch Deck 72 inch Deck
51.6 inches (131.1 cm) 53.6 inches (136.1 cm)
Curb Weight:
LZZ-LP Units:
60 inch Deck
29HP Kawasaki Units 1342 lb (609 kg)
LZAS-LP Units:
60 inch Deck 72 inch Deck
29HP Kawasaki
Units 1283 lb (582 kg) 1338 lb (607 kg)
Accessory Weight Table Worksheet:
Use the table below to determine if extra weight
is required for the unit. Identify the accessories
and correct deck size and place the corresponding
values in the Accessory Score column. If the Total
Accessory Score meets the following, add the
recommended weight kit.
Note: The 72 inch deck does not require a weight kit.
60 inch Deck Accessory Score
Light Kit 2
Michigan
Seat/CRSS 3
Bagger 3
Pneumatic Caster
Tires 5
Mulch Kit -5
Striper Kit 0
OCD02 -4
Hitch Kit 1
Sunshade Kit 2
Total Accessory Score
Total Accessory Score Required Weight Kit(s)
0 – 9 None required
10 – 19 *116-1173 Under toe
board mount weight kit
20 and Higher *Two 116-1173 Under toe
board mount weight kits
or one 116-1173 Under toe
board mount weight kit
and one 116-1238 Front
toe board mount weight kit
*60 inch units which already have an under toe board
mount weight as standard requires 116-1238 front toe
board top mount kit instead of 116-1173.
21
