6
EN
DJI GO/GO 4 App
Press the Power Button until the Monitor powers on, then enter the DJI GO/GO 4 app.
Use the built-in DJI GO/DJI GO 4 app to control the gimbal, camera and other
features of your flight system. The app also comes with a map, a store, and a user
center, for configuring your aircraft and sharing your content.
HDMI
DJI GO
SRE Wi-Fi
Quick setting
Connect your DJI device
DJI GO 4.0
Go Create
11:30
WED, 8 NOV
50%
Applications Explorer Settings
4.0
Specifications
Monitor
Model CS785/ CS785U CS550
Weight Approx. 425 g Approx. 228 g
Dimensions
(without battery)
208.6Ч147.8Ч17 mm 153.76Ч84.94Ч19 mm
Dimensions
(with battery)
208.6Ч147.8Ч34.75 mm 153.76Ч84.94Ч39.6 mm
Touch Screen
7.85‘, IPS screen,
supporting multi-point touch
5.5‘, IPS screen,
supporting multi-point touch
Resolution 2048Ч1536 1920Ч1080
Brightness
CS785: 1000 cd/m2
CS785U: 2000 cd/m2
1000 cd/m2
Storage
CS785: ROM 64GB
CS785U: ROM 128GB
ROM 32GB
Built-in App DJI GO, DJI GO 4
Operating System Android 5.1
Ports
HDMI (Supported 3840×2160 output), Dual SD card slots, USB,
Micro USB, Type-C USB2.0 HS
Network
WIFI frequency band: 2.4GHz, 5.2GHz&5.8GHz*
Protocol: 802.11b, 802.11g, 802.11n (HT20), 802.11a
Supports 4G dongle
EIRP (dBm)
2.4GHz: <20dBm (CE); <30dBm (FCC)
5GHz: <14dBm (CE); <23dBm (FCC)
GNSS GPS/GLONASS
Built-in Modules
Gyroscope, Compass, Speaker, Light-sensitive Sensor,
Microphone
* This image is for reference only. Please refer to the actual user interface.
