4

EN

DO NOT charge the Intelligent Flight battery together with the Intelligent

Battery when using the Inspire 2, Phantom 4 charger or Inspire 2 Car

Charger .

USB power supply port can be used to charge a mobile device of 5V/2A.

Refer to the Charging Hub (WCH2) User Guide for more details.

Mounting the Battery

Put the battery into the Battery Slot, then slide it to the end until you hear a click.

*Use the CrystalSky CS785 for installation illustration.

High

Low

Press the Battery Level Button once to check the battery level.

• Press the Battery Release Button before removing the battery.

• The Intelligent Battery can charge the built-in battery after mounting, which

may reduce the operation time of the Intelligent Battery. The built-in battery

can keep the monitor standby for a short period without the Intelligent Battery,

so you can start the monitor fast once get the Intelligent Battery mounted.

A

B

B

Usage

Charging the Battery

Use the Inspire 2 charger for illustration.*

Place the battery into the standard charging hub, and connect connector B of the

battery charger to the charging hub, then connect the battery charger to a power

outlet (100-240V, 50/60Hz). The Charging Hub will intelligently charge batteries in

sequence according to battery power levels from high to low. The buzzer will begin

beeping when charging is complete. Remove the battery or turn off the Buzzer

Switch to stop it.

The Status LED blinks green when charging and turns solid green when fully

charged.
