14
Connector pin signal layout
Power class
Power class code 100
No power supply from external sources
Fitted with a repeat function with bus power
Jumper
Pin
number
Signal
name
Function
1 VP Cable power supply
2 VG Cable ground
3 TPB* Strobe during receipt, data during transmission
(differential pair)
4 TPB
5 TPA* Data during receipt, strobe during transmission
(differential pair)
6 TPA
Jumper Default position
JP1 2–3
JP2 2–3
