background image

PAS R

APid

L

oAdeR

TM

T

RiMMeR

A

TTAchMenT

o

PeRAToR

'

S

M

AnuAL

11

1. Insert pre-cut 204 mm (8 in.) length of nylon cut-

ting line (recommended sizes 2.4 mm [.095 in.]

to 3.9 mm [.155 in.]) through outside openings of

trimmer head. Minimum of 153mm (6 in.) of line

should extend from each opening. 3.9mm [.155 in.]

line not recommended for trimmers under 28cc.

Level 1.

Parts Required: Pre-cut Nylon Line

NOTE

Insert cutting line ends to center of head recess to insure easy

removal of used lines.

NOTICE:

Nylon line can damage plastic shield. When installing line seg-

ments, make sure line does not curve upward toward shield.

s

Torage

Storage Hook Installation

1. Insert small end of hook into locating hole on attachment shaft.

2. Slide plastic cap onto end of attachment shaft.

Shaft Length ------------------------------------------------ 838 mm (33 in.)
Attachment Width ----------------------------------------- 178 mm (7 in.)
Attchment Height ------------------------------------------ 229 mm (9 in.)
Weight ------------------------------------------------------- 1.36 kg. (3.1 lb.)
Drive Shaft -------------------------------------------------- 6.35 mm (1/4 in.) Flex Shaft
Rotating Direction ----------------------------------------- Counter-clockwise viewed from the top
Cutter Head ------------------------------------------------- Rapid Loader

TM

head (2-lines) with .095 Cross Fire

TM

Line

s

peCIfICaTIons

PAS Rapid Loader

TM

Attachment

MODELS

REQUIRED LINE SIZES

SRM-2100SB

SRM-210SB/211SB/225SB .080 - .105 in.

PAS-210/211/2100

PAS-225/225VP/225VBP

PAS-230/231

SRM-2400SB

.095 - .105 in.

PAS -2400

SRM-260SB/261SB

PAS-2601

.095 - .130 in.

PAS-260/261

PAS-265/266

PAS-280

.095 - .155 in.

nylon

lIne

replaCemenT
