UserÊs Manual 350-700VA Rev B 10
LED & Alarm Status Table
UPS status Green LED Red LED Buzzer
Self test Blink 1 (by turns) B1
AC (Utility mode
Charging ON OFF OFF
Charge off ON OFF OFF
Low battery ON Blink 2 B5
Over load ON Blink 2 B4
DC (Battery
Mode)
Normal Blink 2 OFF B1
Over load Blink 2 OFF B1
Low battery Blink 2 Blink 2 B3
Short/Fault/DC Over-Bat OFF ON ON
AC Over-Bat/Bat Fault OFF Blink 2 B5
Notes:
Blink 1: ON 0.5 seconds / OFF 0.5 seconds
Blink 2: ON 0.25 seconds / OFF 0.25 seconds
B1: 1 beep / 5 seconds ON 0.25 seconds / OFF 4.75 seconds
B3: 2 beeps / 5 seconds ON, 0.25 seconds / OFF 0.25 seconds 2 times 4 seconds OFF
B4: ON 0.5 seconds / OFF 0.5 seconds
B5: 3 beeps / 5 seconds ON 0.25 seconds / OFF 0.25 seconds 3 times 3.5 seconds OFF
Specification*:
Rating 350VA 500VA 700VA
Part Number 31050350A 31050500A 31050700A
Capacity 350VA/210W 500VA/300W 700VA/420W
Dimensions (mm) HxWxD 180x280x115 180x280x115 180x280x115
Unit Weight (kg) 4.5 5 6.5
Input Connection 1.8 metre line cord IEC to Australian 10Amp Plug
Output Connection 6 Australian 10Amp Outlets (3 Battery Backup & Surge Protection,
3 Surge Protection only)
Operation
Input Voltage Range 0-300 VAC
Output Voltage Range Nominal -18% to +10%
On Battery Output Voltage Nominal -12% to +10%
Frequency 50 Hz
Lightning/Surge Protection 476 joules
Safety AS/NZS62040.1.1, AS/NZS60950, A-Tick
EMI AS/NZS62040.2, AS/NZSCISPR22, C-Tick
Transfer Time to Battery/AC 2-6 msec. typical
Battery Type Sealed, maintenance free lead-acid battery
Typical Backup Time 3 minutes at full rated load
Internet/Phone/Fax Protection RJ11
Short Circuit Protection Circuit Breaker
Communication Port USB
Environmental
Operation Temperature 0 o C - 40 o C
Operation Relative Humidity 0 to 95% non condensing
Storage Temperature -15 o C - 50 o C
Software Powerware LanSafe Software is included free of charge
Service Plans Optional Extended Warranty and On Site Changeover service plans available
*Due to continuing product improvement programs, specifications subject to change without notice
