West Penn 3245 16 AWG 4-Conductor Shielded Cable (500', Gray) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 4
• AWG Size 16
• Conductor Stranding 19x29
• Conductor Type Bare copper
• Nominal DCR 4.2 O hm/1000ft
INSULATION PARAMETER -
• Insulation Type Th rmoplastic
• Insulation Thi kness 0.008 in
• Insulation Color Code 1.Black,2.Red,3.White,4.Green
SHIELDING PARAMETER -
• Shield Type Overall 100% Aluminum Foil
• Drain Wire Type Tinned Copper
• Drain Wire AWG 24 AWG
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 40 pF/ft
• Nom. Cap. Conductor to Shield 79 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type PVC
Jacket Thi kness 0.017 in
Nominal Cable O.D. 0.225 in
Plenum No
NEC UL Rating CMR, CMG
RoHS Compliant Yes
Pull Tension 145 lbs
Bend Radius 2.025 in
Cable Weight 56 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability UL1666 Vertical Sha ft
CSA Flammability FT4
Operating Range -20 to 60 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
3245
Audio and Control
16/4 Shielded CMR
Toll Free: 800-245-4964 | [email protected] | www.westpennwire.com
