West Penn 293 18 AWG 2-Conductor Shielded Cable (500', Gray) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 2
• AWG Size 18
• Conductor Stranding 7x26
• Conductor Type Bare copper
• Nominal DCR 6.2 O hm/1000ft
• Cabling Lay Length 1.75 in
• Twists/Foot 6.9 twis t/ft
INSULATION PARAMETER -
• Insulation Type Th rmoplastic
• Insulation Thi kness 0.008 in
• Insulation Color Code 1. Black 2.Red
SHIELDING PARAMETER -
• Shield Type Overall 100% Aluminum Foil
• Drain Wire Type Tinned Copper
• Drain Wire AWG 24 AWG
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 40 pF/ft
• Nom. Cap. Conductor to Shield 79 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type PVC
Jacket Thi kness 0.017 in
Nominal Cable O.D. 0.16 in
Plenum No
NEC UL Rating CMR, CMG
RoHS Compliant Yes
Pull Tension 57 lbs
Bend Radius 1.44 in
Cable Weight 23 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability UL1666 Vertical Sha ft
CSA Flammability FT4
Operating Range -20 to 60 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
293
18/2 Shielded CMR
Audio and Control
Toll Free: 800-245-4964 | [email protected] | www.westpennwire.com
