West Penn 3241 22 AWG 4-Conductor Shielded Cable (500', Gray) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 4
• AWG Size 22
• Conductor Stranding 7x30
• Conductor Type Bare copper
• Nominal DCR 17 O hm/1000ft
INSULATION PARAMETER -
• Insulation Type Th rmoplastic
• Insulation Thi kness 0.007 in
• Insulation Color Code 1.Black,2.Red,3.White,4.Green
SHIELDING PARAMETER -
• Shield Type Overall 100% Aluminum Foil
• Drain Wire Type Tinned Copper
• Drain Wire AWG 24 AWG
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 34 pF/ft
• Nom. Cap. Conductor to Shield 67 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type PVC
Jacket Thi kness 0.017 in
Nominal Cable O.D. 0.142 in
Plenum No
NEC UL Rating CMR, CMG
RoHS Compliant Yes
Pull Tension 42 lbs
Bend Radius 1.278 in
Cable Weight 21 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability UL1666 Vertical Sha ft
CSA Flammability FT4
Operating Range -20 to 60 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
3241
Audio and Control
22/4 Shielded CMR
