12
OVERALL DIMENSIONS Width: 860 mm
Depth: 500 mm
Height: 88 mm
Weight: 16 Kg
CUT OUT DIMENSIONS Width: 830 mm
Depth: 470 mm
T h i c k n e s s : 30 mm
SUPPLY CONNECTIONS Gas:
RC 1/2 inch (1/2 inch male) Rear right hand
corner
Electric:
230 V 50 Hz, 220 V 60 Hz supply, 3 core flexible
cable with non rewireable plug fitted with a 3 amp
cartridge fuse.
HEAT INPUT
Rear Left Burner (semi rapid) 2.0 kW (6824 BTU/HR)
Front Left Burner (rapid) 3.0 kW Natural Gas (10236 BTU/HR)
2.8 kW L.P.G. (9554 BTU/HR)
Central Burner (triple-crown) 4,0 kW (13652 BTU/HR)
Rear Right Burner (semi rapid) 2.0 kW (6824 BTU/HR)
Front Right Burner (auxiliary) 1.0 kW (3412 BTU/HR)
APPLIANCE CLASS 3
APPLIANCE CATEGORY II2H3+
GAS SUPPLY Natural gas G20 / 20 mbar
Instructions for the Installer
Engineers technical data
