4

Communication Functions

Compliance standards

IEEE 802.15.4, ARIB STD-T66

Communication method

Primary modulation: OQPAK

Secondary modulation: DS-SS

Transmission frequency

2405-2475 MHz

Channel

Channel 1-15

Setting: Auto / Manual

Wireless radio ID

0000 to 9999

Setting: Manual

Transmission range*¹*²

Approx. 98.4 ft. / 30 m

Groups

Up to 5 groups (A-E)

* Sender units are set to Group A

Number of possible units
for communication

Up to 16 units of senders and receivers in total

Max. sender units

Up to 15

* Secondary and additional units serve as sub-senders

Max. receiver units

Up to 15

*1: Without any obstructions between senders and receivers, and without radio interference from other devices.
*2: Transmission range may be shorter depending on factors such as how units are arranged, the surrounding

environment, and weather conditions.

Transmission Status Display

Transmission status

Display

lamp

LCD Panel

Sender

Receiver

Connected

Yes

Yes

On (in green)

Sender,

Receiver

Not Connected

Off

Sender,

Receiver

Too many units/Error

Sender,

Receiver

Sub-sender

On (in green)

Sub Sender

Confirmation of linked shooting

Yes

On (in green)

RELEASE

Wireless Firing Control

Wireless firing control via radio transmission

Flash Mode

E-TTL II / E-TTL autoflash
Manual flash
Stroboscopic flash

Group firing

E-TTL II / E-TTL autoflash
Manual flash
Auto external flash metering

E-TTL II / ETTL autoflash

details

ALL

A:B
A:B+C

Manual flash details

ALL

Flash output setting

: 1/

1024*

1,2

to 1/

1

A+B
A+B+C

Stroboscopic flash details

Flash count

1-100

Flash frequency

1-500 Hz

ALL
A+B
A+B+C

Off

Yes

Yes

Yes

Yes

Flash output setting

: 1/

1024

to 1/

4

Flash output setting

: 1/

1024

to 1/

4

Flash output setting

: 1/

1024*

1,2

to 1/

1

Flash output setting

: 1/

1024*

1,2

to 1/

1

Flash output setting

: 1/

1024

to 1/

4

1: Minimum of 1/128 for high-speed sync

2; Speedlites not supporting minimum flash output of 1/1024 fire at a level close to 1/1024
