3

AF Assist Beam

System:

LED

AF-assist beam

Compatible AF System:-

Dual Pixel CMOS AF

Effective Range (Approx.):
At center: 2.0–32.8 ft./0.6–10.0m

Modeling Lamp

Modeling Lamp

Supported

The modeling lamp (LED turns on under the following conditions

Brightness*¹

Manual setting: 1 (Low) to 5 (High)

*Default setting: 5 (High)

Color temperatue

Not supported

On

Illuminated in response to the following operations

• Pressing the button
• Pressing the shutter button halfway twice (with C.Fn-18 set to 1)

Off

Off under the following conditions
• Releasing the shutter button
• Pressing the button
• Pressing the shutter button halfway twice (with C.Fn-18 set to 1)
• Timer: 5 min. / 30 min. / Unlimited (can be changed in P.Fn-0

7

)

*1: set in P.Fn-0

6

Higher LED temperatue from prolonged illumination triggers the following safety functions

Temperature in-

crease

LCD Panel

Modeling Lamp Operation

Icon display

Illumination

Level 1

On

Modeling lamp brightness is lowered one

level, if at the maximum level

Level 2

Blinking

(2 Hz)

Modeling lamp is turned off

Wireless Functions for Radio Transmission

Wireless Settings

Sender

Supported

*Secondary and additional units serve as sub-senders and

display a "SUB SENDER" icon.

* Sub-senders cannot be remotely controlled by a receiver unit

Receiver

Supported

Light emitted

:

Visible Light (white LEDs)
