11
Technical data
Giant binoculars
Product
(Art. No.) Objective lens
type Aperture
(mm) Focal length
(mm) Dimensions
(LxWxH)
(mm) Weight
(kg)
BT-70SF
(0114200) achromatic (2
elem./1 gr.) 70 400 370x213x122 3.4
BT-82SF
(0114210) achromatic (2
elem./1 gr.) 82 470 445x226x122 4.3
BT-100SF
(0114220) achromatic (2
elem./1 gr.) 100 550 520x270x155 6.8
BT-120SF
(0114230) achromatic (2
elem./1 gr.) 120 660 654x290x156 8.3
U-Mount and tripod
Product
(Art. No.) Type Loading
capacity
(kg) Dimensions (LxWxH)
(extended, mm) Weight
(kg)
U-Mount
with tripod
(0114300) Fork arm mount
on steel tripod 12.0 1000x1000x1400 11.3
Cleaning & Maintenance
Giant binoculars
• Clean the lenses (eyepieces and/or objective lenses) only with a soft and lint-free cloth
(e.g. microfibre cloth). To avoid scratching the lenses, use only gentle pressure with the
cleaning cloth.
• To remove more stubborn dirt, moisten the cleaning cloth with an eyeglass-cleaning
solution and wipe the lenses gently.
• Protect the device from dust and moisture! After use, particularly in high humidity, let the
device acclimatise at room temperature for a short period of time, so that the residual
moisture can dissipate. Put the dust caps on and store it in a dry and heated place.
U-Mount and tripod
• Clean the device only on the outside with a dry cloth.
