5
Preparation
Attaching to a Camcorder
This receiver can be inserted into a slot provided on
compatible Sony camcorders.
1
Remove the cover from the slot for the wireless
receiver on the camcorder, and insert the receiver into
the slot.
To avoid inserting the receiver in the wrong direction,
confirm the location of the mounting screws before
inserting the wireless receiver.
2
After inserting the receiver completely into slot,
securely fasten the four mounting screws.
Using Wireless Adapters
Attaching the unit to an optional DWA-01D or DWA-
F01D wireless adapter allows you to use the unit as a
portable wireless receiver.
For details on attaching the unit, refer to the operating
instructions supplied with the DWA-01D or DWA-F01D.
Settings
Setting the Receive Channel
For details about the channel groups and channels that can
be selected, refer to the “Frequency List” on the
CD-ROM.
To prevent interference and noise, beware of the
following.
• Do not use multiple transmitters that have been set to
the same channel at the same time.
• When using two or more channels at the same time,
always configure different channels within the same
group.
• Keep all transmitters and receivers at least 3 m away
from each other.
1
Set the POWER 1 or POWER 2 switch to ON.
2
Press the MENU button to display the RX1 or RX2
menu, and press the + or – button to display the GP/
CH screen.
3
Press and hold the SET button for 1 second or longer.
The channel group display starts flashing.
4
Use the + or – button to select the desired group
name, then press the SET button.
The channel group is set, and the channel number
display starts flashing.
5
Use the + or – button to select the desired channel
number, then press the SET button.
The displays stops flashing and the desired channel is
set.
Receiver
Note
