MediaOne M30 Layout
Passive Speaker (left speaker)
9. TO LEFT SPEAKER - 1/8” (3.5mm)
jack for connecting the passive
left-side extension speaker using
the included two-conductor speaker
cable.
10. AC INLET - Connect the supplied
power cable here
11. Bass Port - Tuned low frequency bass
port for extending the low end of the
speaker cabinets. Do not block the
ports as this will restrict the overall
performance of the speakers.
12. Speaker Connections - 1/8” (3.5mm)
jack for connecting the passive
left-side extension speaker using
the included two-conductor speaker
cable.
