6

O

PERATION

NOTE
These operating instructions modify the instructions in your current
PB-413T/PB-620 Operator’s Manual. Please retain for future refer-
ence.

D

ESCRIPTION

Replaces “Stop Switch” description in Operator’s Manual:

Combination Throttle Position/Stop Switch Button - Controls engine
speed and turns ignition on or off. Forward position - STOP. First
position - IDLE. Move button back to increase speed, forward to decrease
speed. Use Throttle Position Button to set and hold blower speed for
continuous operation.

IMPORTANT
“STOP” position of 9001014 Stop Switch Button is all the way
forward. (“STOP” position of old handle button was all the way back).

Replaces “Throttle Trigger” description in Operator’s
Manual:

Throttle Trigger - Spring-loaded trigger controls engine speed for
intermittent operation. When trigger is released, blower returns to idle, or
to speed set by Throttle Position/Stop Switch Button.

STARTING

COLD

ENGINE

PB-413T/PB-620

1. Replaces Step 1 in Operator’s Manual:

Throttle Position/Stop Switch Button
Slide Throttle Position/Stop Switch Button (A) all the way back to
WOT (Wide Open Throttle) position (first position away from STOP
position.)

2. Follow remaining cold engine starting instructions in Operator’s

Manual.

C

RUISE

C

ONTROL

K

IT

I

NSTALLATION

I

NSTRUCTIONS

13

12

A
