Chapter 2 Hardware Installation
2.1 LED Definition
The faceplate of ENW-9701 has one LED: Link / ACT. The pictures below have showed the faceplate of
ENW-9701. Table 2-1 explains the function and state of the LED.
Link / ACT LED
Faceplate of ENW-9701
LED Description
Link Lights to indicate a functional network link through the port.
Act Blinks to indicate data has been sending and receiving via the port.
Table 2-1 Descriptions of ENW-9701 LED
