1.5: Power Quality
Q Power quality can mean several different things. The terms "power quality" and "power quality
problem" have been applied to all types of conditions. A simple definition of "power quality
problem" is any voltage, current or frequency deviation that results in mis-operation or failure of
customer equipment or systems. The causes of power quality problems vary widely and may
originate in the customer equipment, in an adjacent customer facility or with the utility.
In his book Power Quality Primer, Barry Kennedy provided information on different types of power
quality problems. Some of that information is summarized in Table 1.3 below.
Table 1.3: Typical Power Quality Problems and Sources
Q It is often assumed that power quality problems originate with the utility. While it is true that may
power quality problems can originate with the utility system, many problems originate with
customer equipment. Customer-caused problems may manifest themselves inside the customer
location or they may be transported by the utility system to another adjacent customer. Often,
equipment that is sensitive to power quality problems may in fact also be the cause of the problem.
Q If a power quality problem is suspected, it is generally wise to consult a power quality professional
for assistance in defining the cause and possible solutions to the problem.
Electro Industries/GaugeTech Doc # E107706 V1.25 1-13
