12
2. Slide the cutting attachment onto the shaft housing until the hole
in the neck of the cutting attachment is aligned with the hole (C) in
the housing. (It may be necessary to rotate the saw chain slightly
to align the internal pinion and drive shaft.)
3. Insert locator screw (B) into hole (C) and tighten to snug.
4. Tighten bolts (A), clamping the cutting attachment onto the hous-
ing.
b
C
a
drIve shafT
/
power head
1. Loosen clamping screws (A) and remove locating screw (B).
2. Pull flexible drive shaft (C) 2-3 in. out of drive shaft assembly.
3. Align flexible drive shaft with engine socket and slide together un-
til locating hole in shaft is visible through locating hole in engine
housing.
4. Install locating screw (B) and tighten clamping bolts (A).
B
a
a
B
a
a
C
