Amprobe ACD-330T Clamp-On-Multimeter - Manual (Page 34)

GENERALSPECIFICATIONS
ACDC-300 ACCESSORIES AND REPLACEMENTS PARTS
Amprobe P/N Description
MTL-90B Safety Test Leads (included)
CC-ACDC Carrying Case (included)
MN-1604 9 Volt Alkaline Battery (included)
978762 Instruction Manual (included)
30
Display: Fully annunciated 4-digit liquid crystal display (LCD) with maximum
reading of 4,000 count. Dual display in Temperature mode. 12 segments analog bar
graph. Automatic polarity indication.
Functions: DCV, ACV, DCA, ACA, OHM, Continuity, Frequency and Diode tests.
Measuring rate: 3.3 times per second for V, A, Ohm and Diode tests.
1 ~ 2 seconds per time for frequency test,
Low battery indicator: The " " appears when the battery voltage drops below
7V(approx.).
Operating temperature: Oº C to 50º C (32º F to 122º F), 0 - 80% R.H.
Storage temperature: -20ºC to 60ºC (-4ºF to 140ºF), 0 - 80% R.H. with
BATTERY REMOVED.
Temperature coefficient: 0.12 % / ºC(from OºC to 18ºC or 28ºC to 50ºC).
0.067 % / ºF(from 32ºF to 64.4ºF or 82.4ºF to 122ºF
Powersupply: Single standard NEDA1604, JIS006P,IEC6F22 carbon zinc or
alkaline type 9Vbattery.
MAX. Jaw Opening: To Accommodate Circuit Cables 2.04" (52 mm ) diameter.
Dimension: 32 (H) x 64 (W) x 273 (L) mm / 1,26"(H) x 2.52"(W) x 10.74"(L)
Weight: 860 grams with battery included. (1.9 lbs with battery included.)
Standard Accessories: Test leads (pair), Manual, Battery and Carrying case.
Safety: Designed and manufactured to conform to UL3111-1, C22.2
NO. 1010.1-92 and EN61010 (IEC1010-1, IEC1010-2-031, IEC-1010-2-032)
Installation Category (Overvoltage Category) 11 1000Vor Installation Category III
60OV, Pollution Degree 2 environment.
Note: Meter has been submitted for approval to above standard at the time of print -
ing of this manual. Product will be marked accordingly upon approval.
