SCP 104 Series

sPeCiFiCations

ControL / reMote — ControL Pad

Serial control port . . . . . . . . . . . . . . . RS-232, via a 3.5 mm captive screw connector, 3 pole

Baud rate and protocol . . . . . . . . . 9600 baud, 8 data bits, 1 stop bit, no parity

Serial control

pin configurations . . . . . . . . . . . . . . . A = TX, B = RX, C = GND

IR remote control . . . . . . . . . . . . . . . . IR 402 (for SCP 226 only, optional) 30' maximum, 40 degrees off axis

Program control . . . . . . . . . . . . . . . . . Extron’s Simple Instruction Set (SIS

™

)

GeneraL

Power .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Supplied by an Extron MediaLink

™

Controller or an external power supply

External power supply
(optional)

. . . . . . . . . . . . . . . . . . . . . . . . . . . 100 VAC to 240 VAC, 50/60 Hz, external, to 12 VDC, 1 A, regulated

Power input requirements . . . . . 12 VDC, 0.18 A

Temperature / Humidity . . . . . . . . Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount . . . . . . . . . . . . . . . . . . . . . . Yes, with an optional faceplate, UCM RAAP, part #70-344-02 or 70-344-03

Also wall or furniture mountable

Enclosure type . . . . . . . . . . . . . . . . . . . Metal

Enclosure dimensions
Faceplate
SCP 104

. . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5" H x 4.6" W x 0.1" D (11.4 cm H x 11.7 cm W x 0.3 cm D) (2 gang)

SCP 104 AAP

.. . . . . . . . . . . . . . . . . . . . . 4.5" H x 8.25" W x 0.1" D (11.4 cm H x 21.0 cm W x 0.3 cm D) (4 gang)

SCP 104 L

. . . . . . . . . . . . . . . . . . . . . . . . . 3.2" H x 6.5" W x 0.1" D (8.1 cm H x 16.5 cm W x 0.3 cm D)

Device

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7" H x 3.4" W x 0.5" D (6.9 cm H x 8.6 cm W x 1.3 cm D)

[Allow at least 1.5" (3.8 cm) depth in the wall or furniture. Depth excludes
connectors, knob, and buttons.]

Product weight . . . . . . . . . . . . . . . . . . 0.3 lbs (0.1 kg)

Shipping weight . . . . . . . . . . . . . . . . . 2 lbs (1 kg)

Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . ISTA 1A in carton (International Safe Transit Association)

Listings . . . . . . . . . . . . . . . . . . . . . . . . . . . . UL, CUL

Compliances . . . . . . . . . . . . . . . . . . . . . CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,000 hours

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 3 years parts and labor

NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.

M e d i a L i n k

™

c o n t r o L L e r a c c e s s o r i e s

SCP 104 Series Accessories

oPtionaL aCCessories

ModeL desCriPtion

PaGe

Part #

MLC 104 IP Plus

MediaLink

™

Controller with IP Link

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

page 383

60-818-02

EPS 1210 B

Extron Desktop Power Supply - 12VDC, 2A

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

page 694

70-055-01

MR 200

Two-Gang Mud Ring

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

page 821

70-519-22

MR 400

Four-Gang Mud Ring

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

page 821

70-519-42

MLM 104 L

Replacement Lectern Mounting Kit for the MLC 104 IP Plus

. . . . . . . . . . . . . . . . . . . . .

page 404

70-357-02

MLM 104 4GWP

Four-Gang Replacement Wall Mounting Kit for the MLC 104 IP Plus

. . . . . . . . . . . .

page 403

70-379-02

SMB 102

Two-Gang Surface Mounting Box

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

page 824

60-640-02

SMB 104

Four-Gang Surface Mounting Box

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

page 824

60-642-02
