2
1.2 PACKAGE CONTENTS
- Digital Video Recorder x1
- Screws x 1 pack with Plum wrench
- GPS Antenna x 1 set
- IR Remote Control x 1
- Battery x 2
- Camera Power cable x 1
- Video & Audio cable x 1
- RS232/Alarm cable x 1
1.3 SPECIFICATIONS
EMV200 EMV200 EMV200 EMV200 ---- 2CH Mobile DVR 2CH Mobile DVR 2CH Mobile DVR 2CH Mobile DVR
Video Format NTSC/PAL (auto detected by system)
Operating System Embedded Linux with special small monitor friendly GUI
Video Input 2 channels (vibration resistant locking Molex connectors – Interface cables to
BNC-F provided)
Video Output Main monitor: 1 composite 1 Vp-p, (vibration resistant locking Molex connectors –
Interface cables to BNC-F provided)
Video Compression H.264
Recording Resolutions
(Rate and resolution set
independently per camera) NTSC: 704x480/ 704x240/352x240
PAL: 704x576/ 704x288/352x288
Audio Inputs 2 line in (vibration resistant locking Molex connectors - Interface cables to RCA-F
provided).
Audio Outputs 1 line out (vibration resistant locking Molex connectors - Interface cables to RCA-
F provided).
Alarm Inputs 2 alarm inputs (vibration resistant locking Molex connectors - Interface cables
supplied)
Alarm Outputs 1 alarm relay output SPDT/Form “C” (vibration resistant locking Molex
connectors - Interface cables supplied)
Recording Storage 1 SD/SDHC card storage card Up to 32Gb with tamper resistant retention cover
Recording Rate
(Rate and resolution set
independently per camera) Up to NTSC: 60fps, PAL: 50fps at all resolutions (D1, 2 CIF, CIF)
Recording Mode Continuous recording, event recording, continuous + event recording (Rate and
resolution in each mode set independently per camera)
Record Quality Adjustable in five levels per camera per Record Mode
Pre Alarm Recording Optional; 5 second interval
Playback Rate Up to NTSC: D1 60fps, PAL: D1 50fps
Playback Search Time/date, event search
Video Loss Detection Yes
