33 CS-352
* Technical data subject to change without notice.
TECHNICAL DATA
MODEL CS-352
Dimension L × W × H mm 396 Ч 232 Ч 268 (15.6 in. × 9.1 in. × 10.6 in.)
Mass Power head, dry kg 4.0 (8.8 lb.) Without chain and guide bar
Engine Type Air-cooled two-stroke single cylinder
Displacement mL (cm³) 34.0 (2.075 cu. in.)
Carburetor Diaphragm type
Magneto Flywheel magneto: CDI system
Spark plug NGK BPM8Y
Starter Recoil starter
Power transmission Automatic centrifugal clutch
Fuel Mixture ratio 50 : 1 ratio with ECHO Power Blend X™, ISO-L- EGD
(ISO/CD 13738) and JASO M345-FD two-stroke,
air-cooled engine oil.
Gasoline Use 89 octane unleaded.
Do not use fuel containing methyl alcohol, more than
10 % ethyl alcohol or 15 % MTBE.
Do not use alternative fuels such as E-15 or E-85.
Tank capacity L 0.25 (8.47 US. fl. oz.)
Oil Bar and chain ECHO bar and chain oil (or motor oil)
Tank capacity L 0.26 (8.81 US. fl. oz.)
Guide bar and See page 23 for Chain and Guide Bar Combination
saw chain
Lubrication Non-adjustable automatic oil pump
Engine speed Idle r/min 3,000
Clutch engagement r/min 4,200
Wide open throttle r/min 12,250
Standard Front hand guard, Rear hand guard,
features Anti-vibration device, Throttle control lockout,
Chain brake, Chain catcher, Spark arrestor muffler,
Kick guard, (Spiked bumper; Option)
