23 CS-352
CHAIN AND GUIDE BAR COMBINATION
The following combinations are recommended for model CS-352.
Guide Bar Saw chain
Length Part No. Pitch Part No. Links
mm (in) Double Guard mm (in)
305 (12) 12A0CD3745 9.53 (3/8) 91PX, 91VG 45
356 (14) 14A0CD3752 9.53 (3/8) 91PX, 91VG 52
406 (16) 16A0CD3757 9.53 (3/8) 91PX, 91VG 57
Saw CHain
(Low-kickback)
CaUTiOn
Do not use replacement saw chain unless
it has been designated as meeting the anSi
B175.1 kickback performance requirements,
when tested on the representative sample of
chain saws below 3.8 c.i.d. specified in ANSI
B175.1.
nOTE
LOW KICKBACK SAW CHAIN meets the
kickback performance requirements of ANSI
B175.1 (safety requirements for gasoline-
powered chain saws).
gUiDE Bar
(Low-kickback)
Replacement guide bars.
The following guide bars may be considered to
have equivalent kickback energy.
• Sprocket nose guide bars of the same length and
nose radius, same pitch and having the same
number of teeth.
• Hard nose guide bars of the same length and
nose radius as a sprocket nose bar.
iMPOrTanT
Chain and guide bar gauge size must be identical. Use Bar/Chain combinations shown in table above.
iMPOrTanT
If your kick guard is damaged or lost, contact your Echo dealer for a replacement. For the name of the
Echo dealer nearest you, Call: 1-800-432-ECHO (3246) or on the web at www.echo-usa.com.
Refer to your Chain Saw Safety Manual for kick guard application information.
warning
Use of replacement saw chain and/or guide bar other than that specified, or operation without the “tip guard” in
place, may cause severe kickback resulting in serious injury.
Only use saw chain designated as, “LOW-KICKBACK,” that meets the ANSI B175.1 Standards when tested on
the representative sample of chain saws below 3.8 C.I.D., and the Echo guide bar specified.
