14
SPECIFICATIONS
ED-200
Mass without drill bit kg 4.4 (9.7 lbs)
Volume
fuel tank L 0.5 (16.9 US,fl.oz.)
Drill
size mm 32 - 178 (1.25 - 7 inch)
chuck capacity mm 13 (0.5 inch)
speed r/min 430
Mission
reduction ratio 20.5
lubrication grease
External Dimensions
length × width × height mm 395 Ч 325 Ч 255
without drill bit (15.5 Ч 12.8 Ч 10.0 inch)
Engine
type Air cooled Two stroke single cylinder
engine displacement mL (cm 3 ) 21.2 (1.29 cu. inch)
recommended maximum engine speed r/min 9,000
recommended engine idling speed r/min 2,900
engine speed at beginning of clutch engagement r/min 4,000
carburetor diaphragm type
ignition flywheel magneto - CDI system
spark plug NGK BPM8Y
starter recoil starter
clutch automatic Centrifugal
Fuel
mixing ratio Mixture of gasoline (unleaded, 89 octane
minimum) and specially blended 50 : 1
ECHO two cycle engine oil.
fuel consumption at engine maximum power L/h 0.47 (15.9 US,fl.oz.)
