Rosemount Analytical Inc. A Division of Emerson Process Management Replacement Parts 5-1
Model NGA2000 HFID
SECTION 5
REPLACEMENT PARTS
WARNING
PARTS INTEGRITY
Tampering with or unauthorized substitution of components may adversely affect safety of this
product. Use only factory-approved components for repair.
5-1 MATRIX
Each analyzer is configured per the customer sales order. Below is the HFID sales matrix which lists the
various configurations available.
To identify the configuration of an analyzer, locate the analyzer name-rating plate. The 12-position sales
matrix identifier number appears on the analyzer name-rating plate.
HFID Heated Flame Ionization Detection Analyzer Module
Code Software Version
01 Standard
02 2.3 Version Software
99 Special
Code Configuration Identifier
A1 Mixed Fuel, 4 Selectable Ranges: 0-10 to 0-10,000 ppm CH
4
A2 Mixed Fuel, 4 Selectable Ranges: 0-100 to 0-10,000 ppm CH
4
H1 Mixed Fuel, 4 Selectable Ranges: 0-100 ppm to 0-5% CH
4
99 Special Calibrated Ranges
Code Cable Selection
00 None
A1 Standard (3 ft LON and Pwr AM to Platform)
B1 System (10 ft LON and Pwr AM to 30A PS)
Code Special Requirements
00 None
G1 Customer Option
99 Special
HFID 01 A1 A1 00 Example
