SPECIFICATIONS DESCRIPTION
Anaheim • Raleigh • Silicon Valley • Dallas • New York • Washington, DC • Toronto • Mexico Cit y • Paris • London • Fr a n k f u r t
Amersfoor t • Moscow • D u ba i • Jo h a n n e s bu rg • N ew De l h i • B a n g a l o re • S i n g a po re • S eou l • S h a n g h a i • Be i j i n g • To k yo
UNITED STATES EUROPE ASIA MIDDLE EAST
Worldwide Sales Offices
+800.633.9876
Inside USA/Canada
+1.714.491.1500
+800.3987.6673
Inside Europe
+31.33.453.4040
+800.7339.8766
Inside Asia
+65.6383.4400
+971.4.299.1800
01-2013
68-1590-01
REV. A1
Letter - English - NP
© 2013 Extron Electronics. All rights reserved. All trademarks mentioned are the property of their respective owners. Prices and specifications subject to change without notice.
For complete specifications, please go to www.extron.com
Specifications are subject to change without notice.
VIDEO INPUT
Number/signal type 1 RGBHV, RGBS, RGsB, HDTV component video
(Y, R-Y, B-Y)
Formats RGB and HDTV Y, R-Y, B-Y
VIDEO OUTPUT
Number/signal type
RGB-DVI 300
1 single link DVI-D
RGB-HDMI 300 A 1 single link HDMI
Formats RGB and YCbCr digital video
AUDIO INPUT — RGB-HDMI 300 A
Number/signal type 1 stereo, unbalanced
AUDIO OUTPUT — RGB-HDMI 300 A
Number/signal type 1 stereo, digital LPCM 48 kHz (embedded in HDMI output)
CONTROL/REMOTE — SCALER
Serial control ports 1 RS-232, 3.5 mm captive screw connector, 3 pole
(rear panel)
1 RS-232, 2.5 mm mini stereo jack (front panel)
GENERAL
Power supply External
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 1 A, 12 watts
Power consumption
RGB-DVI 300
Device and power supply
10.0 watts, 100-240 VAC, 50-60 Hz
RGB-HDMI 300 A
Device and power supply
14.0 watts, 100-240 VAC, 50-60 Hz
Temperature/humidity Storage -40º to +158ºF (-40º to +70ºC) /
10% to 90%, noncondensing
Operating +32º to +122ºF (0º to +50ºC) /
10% to 90%, noncondensing
Mounting
Rack mount
Yes, with optional rack shelf kit and RFF 052 false front
Wall mount Yes, with optional under-desk or through-desk mounting
kit
Enclosure dimensions 1.0 H x 8.75" W x 6.0" D (half rack wide)
(2.5 cm H x 22.2 cm W x 15.2 cm D)
(Depth excludes connectors and knobs.)
Product weight 1.6 lbs (0.7 kg)
Vibration ISTA/NSTA 1A in carton (International Safe Transit
Association)
Regulatory compliance
Safety
CE, c-UL, UL
EMI/EMC CE, C-tick, FCC Class A, ICES, VCCI
Environmental Complies with the appropriate requirements of WEEE.
MTBF 30,000 hours
Warranty 3 years parts and labor
NOTE: All nominal levels are at ±10%.
Model Version Description Part number
RGB-DVI 300 RGB to DVI Scaler 60-906-01
The Extron RGB-DVI 300 is a high performance RGB to DVI scaler
that converts incoming analog component video and RGBHV signals
to DVI-D signals. It accepts HDTV and high resolution computer-
video signals up to 1920x1200, and offers multiple output rates
up to 1920x1200, including HDTV 1080p/60. The RGB-DVI 300 is
housed in a compact, low-profile enclosure for discreet installation
behind a display or above a projector. The RGB-DVI 300 is ideal for
applications where displays, equipped only with DVI or HDMI inputs,
are to be used with sources that output analog RGB computer-
video, or in an environment with an existing analog RGB signal
distribution infrastructure.
FEATURES
A Input: RGBHV or component video on 15-pin HD
A Output: DVI digital on DVI-I
A Auto Input Format Detection – The RGB-DVI 300 can be set
to detect the incoming RGB or HD component video signal
format, automatically reconfiguring itself to provide the appropriate
decoding and signal processing.
A EDID Emulation – The RGB-DVI 300 provides a means for
specifying the rate of the incoming signal, ensuring proper
communication with the VGA source.
A Output Standby Mode – The RGB-DVI 300 can be set to
automatically mute video and sync output to the display device
when no active input signal is detected. This allows the projector
or flat-panel display to automatically enter into standby mode to
save energy and enhance lamp or panel life.
A Memory presets – Memory presets are available to store
and recall sizing, centering, detail, contrast, and brightness
information.
A Aspect ratio control
A Auto-Image ™ setup
A Auto Input Memory
A Output color space selectable as RGB or digital
component video
A Picture controls for brightness, contrast, detail, horizontal
and vertical positioning, sizing, and zoom
A On-screen display
A RS-232 control port
A Internal test patterns for calibration and setup
A 1" high, half rack width metal enclosure
