Epson EB-W6 New Product Summary (06.08.2008)
Specifications
Model EB-W6
Projection System RGB liquid crystal shutter projection system
Projection Method Front / Rear / Ceiling mount
Specification of
Main Parts
LCD Size 0.56 -inch without MLA
Driving Method Poly-silicon TFT active matrix
Pixel Number 1,024,000 dots (1280 x 800)
Native
Resolution WXGA
Aspect Ratio 16:10
Pixel
Arrangement Cross stripe
Refresh Rate 50 Hz - 60 Hz
Projection
Lens
Type Digital zoom / Manual focus
F-Number 1.6 – 1.74
Focal Length 18.4mm – 22.12mm
Zoom Ratio 1-1.2
Lens Cover Slide lens shutter
Lamp Type 170 W UHE
Life 3000 hours (Brightness Control: High)
4000 hours (Brightness Control: Low)
Optical System Dichroic Mirror Separation & Prism combine
Method
Screen Size (Projected Distance) 27" to 270" [1.0 to 10.4 m] (Zoom:Tele)
27" to 270" [0.84 to 8.7 m] (Zoom:Wide)
60" screen 1.9 - 2.3 m
Offset 10:1
High 2000 lm (Colour mode: Game, Zoom: Wide) Light Output
(Brightness) Low 1590 lm (Colour mode: Game, Zoom: Wide)
Contrast 2000:1
Light Output Uniformity Typ. 90%
Colour Reproduction Full-Colour (16.77 million Colours)
Video Quality Simple Interlace-Progressive conversion
Sound Output 7 W Monaural
Speaker 71mm x 41mm in diameter x 1
Function User logo, A/V mute, Freeze, E-Zoom, Help
Colour Mode PC: Photo, Presentation, Theatre, Game, sRGB,
Blackboard, Text
Video: Sports, Presentation, Theatre, Game,
sRGB, Blackboard, Text
Remote Control Infrared Receiver Position / Distance
/ Directivity
Front & Rear, 6 m
Right / Left: -30 to +30 degrees
Upper / Lower: -15 to +15 degrees
Effective Scanning
Frequency Range
(Analogue)
Pixel Clock 13.5 MHz to 162 MHz
up to UXGA 60 Hz
Horizontal 15 kHz to 92 kHz
Vertical 50 Hz to 85 Hz
Adjustment
Function
Projector / Remote Control Brightness / Contrast / Tint / Saturation /
Sharpness / Input signal / Sync / Tracking /
Position /
Colour temperature / Volume / etc.
Foot Adjuster Front-centre
Tilt Angle 0 to 11 degrees
Keystone Correction Vertical: -30 to +30 degrees
Auto Keystone Correction Yes
Source Search Yes
Auto Detection of
RGB/Component
Yes
Operation Panel Protected
Function
Yes
Password Protected Function
(Security Function)
Yes
Other Function USB Display USB Display Ver.1.40 (for Windows)
Analogue RGB I/O Display
Performance
Native 1280 x 800 dots
Input Signal Signal Type Separate signal
Video Signal Analogue (0.7 Vp-p, 75 ohm / Mac 0.714 Vp-p,
75 ohm)
Sync. Signal Separate (positive & negative, bi-polarity 2-5 Vp-
p)/
Composite (positive & negative, bi-polarity 2-5
Vp-p)/
Sync-on-green (negative, 0.3 Vp-p)
Audio Signal 500 mVrms / 47 k-ohm
Input Terminal Video D-sub 15pin x 1 Blue moulding
Audio RCA x 1 (White/Red)
Output Signal Video Signal Analogue (0.7 Vp-p, 75 ohm / Mac 0.714 Vp-p,
75 ohm)
Sync. Signal Separate (positive & negative,TTL) /
Composite (positive & negative,TTL) /
Sync. on green (negative 0.2-0.4 Vp-p)
Output
Terminal
Video D-sub 15pin x 1 Black moulding
(Output signal : Computer * only)
Display
Performance
Native 1280 x 800 dots
Input Signal Version 1.3a
Video
Standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Signal TMDS(TMDS is signal for HDMI)
Audio Signal Linear PCM
Input Terminal HDMI
HDMI
HDCP Yes
Video I/O Display
Performance
NTSC: 560 lines, PAL: 560 lines
Input Signal Video
Standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL /
PAL60 / SECAM
Video Signal Composite Video (1.0 Vp-p / Sync.negative, 75
ohm) /
S-Video (Luminous 0.714 Vp-p, Chrominous
0.286 Vp-p, 75 ohm) /
Component Video (Analogue Y level 0.7 V, 75
ohm / Cr Cb level
+/-0.35 V, 75 ohm / sync.negative 0.3 V or 3-
state +/-0.3 V on Y) /
RGB Video (0.7 Vp-p, 75 ohm / Mac 0.714 Vp-p,
75 ohm)
Audio Signal 500 mVrms / 47 k-ohm
Input Terminal Video Composite Video: RCA (Yellow) x 1
S-Video: Mini DIN x 1
Component Video: D-sub 15pin Blue moulding
(in common with Analogue RGB connector)
RGB Video: D-sub 15pin Blue moulding
(in common with Analogue RGB connector)
Audio RCA x 1 (White/Red)
(in common with Analogue RGB Audio terminal)
USB Display Input Signal Video Yes
USB I/O I/O Terminal Type B x1 (for USB Display, Mouse, K/B,
Control) Control I/O
I/O Speed USB Type B Ver. 2.0
Memory I/O USB I/O I/O Terminal USB Type A x 1 (For USB Memory)
I/O Speed USB Type A Ver. 1.1
SD I/O I/O Terminal SD Memory Card Slot x 1
I/O Speed High Speed
Operating
Temperature
5 °C to 35 °C <41 °F to 95 °F> ( 20%-80%
Humidity )
Thermal shut down > 45 °C
Operating Altitude 0 m to 2286 m<0 ft to 7500 ft>
( over 1500 m / 4,921 ft :with High altitude mode)
Direct Power On Yes
Direct Power Off Yes
Start-up Period about 5 seconds
warm-up period: 30 seconds
Cool-down Period Instant off
Exhaust Direction Side
Air Filter Standard Yes
Padlock & Security Cable Hole Yes Theft Proof
Kensington Lock Yes
Power Supply
Voltage
100 - 240 V AC +/- 10%, 50/60 Hz
Power
Consumption
100-120V Area
(JAPAN, USA,
etc)
Lamp On 246 W
Standby
(Network On)
N/A
Standby
(Network Off)
3 W
220-240V Area
(Europe, etc)
Lamp On 231 W
Standby
(Network On)
N/A
Standby
(Network Off)
4.3 W
Except JAPAN 100 - 240 V AC 50/60 Hz 2.8 - 1.5 A
Exclude Feet (D x W x H) 245 x 327 x 92 mm Dimension
Maximum Dimension (D x W x
H)
245 x 327 x 101 mm
Weight
Approx. 6.2 •bs. / 2.8kg
Brightness Control: High 35 dB Fan Noise
Brightness Control: Low 28 dB
Compatible
Standard
Safety US UL60950-1 1st edition (cTUVus Mark)
Canada CSA C22.2 No.60950-1
Japan The electrical appliance safety law / TV receiver
Europe IEC 60950-1 1st edition (CE Marking)
Germany German Equipment and Product Safety Law (GS
Mark)
Korea EK
China CCC (GB4943)
Singapore PSB
Mexico NOM
EMC US FCC part 15B class B
Canada ICES-003 class B
Japan The electrical appliance safety law / TV receiver
CE(Europe) EMC directive (89/336/EEC)
Korea MIC-Mark
China CCC (GB9254, GB 17625.1)
Australia/New
Zealand C-tick Mark
Environmental
Protection US State's law for packages
Japan Recycling regulation for packages
Germany &
France A law for waste product evasion
CE(Europe) Dioxide regulation
All countries Recycling regulation
Supplied
Accessories
Power Cable 1.8m
Computer
Cable 1.8 m D-sub 15pin (Male) - D-sub 15pin(Male)
USB Cable 1.8 m, USB A/USB B
Remote
Control Compact type
Battery Manganese dry cell x 2
Password Protect Sticker Included
User's Manual
Set Included
Soft Carry Case Included
Optional
Accessories
Spare Lamp ELPLP41
Air Filter Set ELPAF13
Soft Carrying
Case ELPKS16B
50” Portable Roll Screen ELPSC06
60” Portable Roll Screen ELPSC07
80” Portable Roll Screen ELPSC08
100 Type
Screen ELPSC10
Computer
Cable HD15 / HD15,
1.8 m ELPKC02
Computer
Cable HD15 / HD15,
3.0 m ELPKC09
Computer
Cable HD15 / HD15,
20.0 m ELPKC10
Component
Video Cable HD15 / 3RCA
(male),
3.0 m ELPKC19
Ceiling Mount White Colour ELPMB23
Suspension
Adapter
450mm White Colour ELPFP13
Suspension
Adapter
700mm White Colour ELPFP14
Errors and omissions excepted, all specifications are subject to change without
notice.
