8
E
F
D
PR185
F
F
F
Your appliance needs air
For safety reasons, minimum ven-
tilationmust be as shown Fig.
Attention: keep ventilation ope-
nings clear of obstruction;
NP005
100 mm
10 mm 10 mm
Rehingeing the door
The side at which the door opens can be changed from the right side
(factory adjustment) to the left side, if the installation site requires.
Warning! When changing the side at which the door opens, the
appliance may not be connected to the mains. Remove plug from the
mains beforehand.
Procced as follow:
1. Remove the clip-in ventilation grille
(D).
2. Remove the bottom hinge (E) by
unscrewing the two fixing screws.
3. Slide the bottom door off the centre
hinge (H).
Rear spacers
In the bag with the documentation,
there are two spacers which must
be fitted.
slacken the screws and insert the
spacer under the screw head, then
re-tighten the screws.
PR153
