Display Color and Gray Scale Reference
Color
Input Color Data
Red Green Blue
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Basic
Color
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red (63) 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Green (63) 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Blue (63) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Cyan 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 0 0 0 0 0 0 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Gray
Scale
of
Red
Red (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Dark 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0
: : :
: : :
1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0
Light 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0
Red (63) 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Gray
Scale
of
Green
Green (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Dark 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0
: : :
: : :
0 0 0 0 0 0 1 1 1 1 0 1 0 0 0 0 0 0
Light 0 0 0 0 0 0 1 1 1 1 1 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Gray
Scale
of
Blue
Blue (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0
: : :
: : :
0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 0 1
Light 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 0
Blue (63) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
