System Connection
3. System Connection
The installations described below should be made by qualified service personnel or system installers.
Before Installation
Please refer to the following diagram for the system connections.
TP-S109DR: Camera 1~9 / TP-S1016DR: Camera 1 ~ 16
~
5
CALL Monitor
Audio Input
(camera Audio Out) Audio Out
(To Speaker)
MAIN Monitor
Ethernet
RS232
Alarm In/Out
RS485
Remote Keyboard(s)
KS-KBJ / KS-KBK
(optional)
