professional control surface
Artist Series
USER GUIDE
SURFACE CONTROLS
37
4.5.4 Dual-Function Knobs
Some knobs have two functions that are toggled by pressing the knob’s SEL key
(i.e., EQ Frequency and Q). The knob name changes in the display to show the
current function. Dual-function knobs are supported in normal mode.
4.5.5 Knob Set Navigation Keys
Since a knob set may have more parameters than knobs, the PAGE W and
PAGE X keys scroll among them.
Figure 4-12 Knob Set navigation keys
PAGE W
Press the PAGE W key to scroll to the previous page. When on the first page,
pressing PAGE W key does nothing. The PAGE W key lights yellow when there is
a previous page to go to.
PAGE X
Press the PAGE X key to scroll to the next page. When on the last page, pressing
the PAGE X key does nothing. The PAGE X key lights yellow when there is a next
page to go to.
Configuration Pages (CFG)
Many knob sets have a configuration page to set up that knob set. The configu-
ration page for the Inserts knob set, for example, is used to assign plug-ins to a
track. The configuration page for the Aux knob set assigns aux sends to a track.
Some applications can configure presets for plugins and EQs.
Press the PAGE W + PAGE X keys simultaneously to display a knob set’s config-
uration page, if it has one. When on the configuration page, both the PAGE W
and PAGE X keys light.
SEL
ON
BACK
TOP
CFG
PAGE
CFG
PAGE
SOLO ON
