Rugged Cams Fusion DVR User Manual
Page 23
23
[Picture1-3-1] Motion Zone selection screen
Go Right
Go Up
Use to enable Sensor triggered recording S
FF
Use to enable Motion detection triggered recording. M
PLAY/PAUSE
Use to Disable recording setting.
F/REW
Use to set Continuous recording mode. C
REW
Description
Buttons
1-3-1. Motion Detection Setup
By selecting Partial Zone in the Motion Zone menu, user can set-up the motion
sensing zones in the screen. Move around each rectangular zone using 4 direction
key buttons and press SEL button to include the rectangular region as part of the
motion sensing zone. The rectangular blocks included as part of the motion zone are
indicated by changing the color of the blocks.
1-3-2. Schedule Recording
You can select your type of recording (Motion, Sensor, or Continuous) at one hour intervals
for the week.
