2.10.5 Deck Drive: Electric clutch mounted on horizontal engine shaft. “B” Section belt
(with self-tensioning idler) from electric clutch to transfer shaft mounted on deck.
Blades are driven by one “B” Section belt (w/self-tensioning idler) from transfer
shaft on deck to blade spindles.
2.10.6 Deck: Full floating deck is attached to out-front support frame. Six anti-scalp
rollers provide maximum turf protection. Dual deck support shafts add to the
stability of the deck. Deck design allows for bagging, mulching or side discharge.
Deck Depth:
52” Deck (Serial Nos. 259,999 & Lower): 5.0” (12.7 cm)
52” Deck (Serial Nos. 260,000 & Higher: 5.5” (14.0 cm)
60” Deck (Serial Nos. 160,000-189,999): 5.0” (12.7 cm)
60” Deck (Serial Nos. 190,000
& higher): 5.5” (14.0 cm)
72” Deck: 5.5” (14.0 cm)
2.10.7 Cutting Height Adjustment: an extra-long cushioned lever is used to adjust the
cutting height from 1 1/2” (3.8 cm) to 5” (10.2 cm.) in 1/2”(1.3 cm.) increments
for Serial Nos. 160,000-189,999 and 1/4”(.64 cm) increments for Serial No.
190,000 & higher. The cutting height adjustment handle has a transport position
and all adjustments can be made while the operator remains seated. Kohler 26
HP EFI units and all 72” units also have a foot operated deck lift assist lever to
aid in raising the deck. (The deck lift assist lever is an optional accessory for all
other units.)
2.10.8 Mulching Kit: Optional.
2.11 Dimensions
2.11.1 Overall Width:
without deck deflector up deflector down
Serial Nos. 160,000-259,999 w/52” Deck 49.8 in. (126.5 cm) 53.4 in. (135.6 cm) 63.1 in. (160.3 cm)
Serial Nos. 260,000 & Higher w/52” Deck 49.8 in. (126.5 cm) 53.4 in. (135.6 cm) 64.2 in. (163.1 cm)
Serial Nos. 160,000-189,999 w/60” Deck 53.8 in. (136.7 cm) 61.4 in. (156.0 cm) 71.0 in. (180.3 cm)
Serial Nos. 190,000 & Higher w/60” Deck 53.5 in. (135.9 cm) 61.4 in. (156.0 cm) 72.9 in. (185.2 cm)
Serial Nos. 190,000 & Higher w/72” Deck 57.3 in. (145.5 cm) 73.2 in. (185.9 cm) 84.3 in. (214.1 cm)
2.11.2 Overall Length:
All Air-cooled units - w/52” & 60” decks - 78.5 in. (199.4 cm)
w/72” deck – 82.6 in. (209.8 cm)
Kawasaki Liquid-cooled units – w/52” & 60” decks – 80.7 in. (205.0 cm)
w/72” deck – 84.8 in. (215.4 cm)
2.11.3 Overall Height:
Serial Nos. 160,000-189,999: 44 in. (111.8 cm.)
Air-cooled units Serial Nos. 190,000
& higher: 44.5 in. (113.0 cm.)
Kawasaki Liquid-cooled units – 47.7 in (121.2 cm)
2.11.4 Tread Width: (center to center of tires, widthwise)
Drive wheels:
Serial Nos. 160,000 & Higher w/52” Deck – 39.7 in. (100.1 cm)
Serial Nos. 160,000
– 189,999 w/60” Deck - 43.7 in. (111.0 cm)
Serial Nos. 190,000 & Higher w/60” Deck – 41.9 in. (106.4 cm)
Serial Nos. 190,000 & Higher w/72” Deck – 45.9 in. (116.6 cm)
Casters:
w/52” Deck – 37.0 in. (93.9 cm)
w/60” Deck – 39.0 in. (99.1 cm)
w/72” Deck – 47.6 in. (120.9 cm)
